ISUZU Clutch Disc 250mm X 24T Rau NHR NKR NPR NQR TFS UBS UCS OEM 8971354920 8980806610
Hwm 250mm 24T clutch disc rau ISUZU N-Series (NKR, NPR) & Pickups (TFS, UBS). 4 kev xaiv zoo: Nyiv Qhov Tseeb / BVP / High-Kev Ua Haujlwm Tom Qab / Tuam Tshoj ISUZU (Qingling) zoo rau Xaiv. Ib - nres ISUZU qhov chaw xa khoom txij li xyoo 1997.
Hauj lwm lawm
Khoom Description
Txhawm rau kom paub meej qhov haum, thov txheeb xyuas cov kev txwv hauv qab no rau koj lub tsheb:
|
Parameter |
Specification Paub meej |
|
Khoom npe |
ISUZU Clutch Disc / Clutch Phaj / Friction Phaj |
|
OE / OEM Naj Npawb |
8971354920 8980806610 8980116820 8973778990 8972571240 8972179850 8972072450 8970805640 8943752480 8970663450 8971041090 5876100831 / 8-97135492-0 8-98080661-0 8-98011682-0 8-97377899-0 8-97257124-0 8-97217985-0 8-97207245-0 8-97080564-0 8-94375248-0 8-97066345-0 8-97104109-0 5-87610083-1 |
|
Sab nraud |
250 hli |
|
Sab hauv |
160 hli |
|
Tus naj npawb ntawm cov hniav |
24T |
|
Hub Profile |
25.6mm 3 |
|
Thickness |
Txheem OEM thickness rau kev pom kev koom tes |
|
Net nyhav |
Kwv yees li . 2.0 kg - 2.2 kg |
|
Khoom siv |
Premium Asbestos-dawb, Siab- kev sib txhuam sib xyaw (Semi- xim hlau xaiv muaj) |
|
Nto tiav |
Los tiv thaiv -corrosion txheej ntawm lub hub |
| Truck haum rau | Isuzu NHR/NKR/NPR/NQR/TFS/UBS/UCS |
| Cav haum rau | 4JB1T/4KH1 |
|
Qauv |
Dual -damper caij nplooj ntoos hlav system rau txo kev co |
|
Qib Qib |
Nyiv Qhov Tseeb / BVP / Siab -Kev Ua Haujlwm Tom Qab / Tuam Tshoj ISUZU (Qingling) zoo rau Xaiv |
Txhim kho koj lub tsheb kev sib kis tau zoo nrog peb tus nqi250mm x 24T Clutch Disc, tshwj xeeb engineered rauISUZU N-Series tsheb loj thiab D-MAX/Trooper qauv. Txawm hais tias koj tab tom nrhiav rau qhov tseeb ntawm Japanese engineering lossis tus nqi zoo tshaj plaws rau kev saib xyuas lub nkoj, peb muab peb cov qib zoo sib xws kom tau raws li koj cov kev xav tau tshwj xeeb.
Nrog29 xyoo ntawm kev txawj ntsenyob rau hauv ISUZU nws pib qhov chaw, peb xyuas kom meej tias txhua qhov disc muab kev hloov kho kom zoo, txo kev co, thiab kev pab lub neej ntev.
Clutch Pressure Phaj Taw Qhia
Clutch Pressure Phaj yog dab tsi?
Lub clutch siab phaj yog ib qho tseem ceeb ntawm lub clutch system, mounted nruab nrab ntawm lub flywheel thiab lub clutch disc.Nws siv lub zog clamping quab yuam los tuav lub clutch disc nruj nreem tiv thaiv flywheel, tso cai rau lub cav torque kis tau tus mob.
Thaum lub clutch pedal nias, lub phaj siab tso tawm nws lub zog clamping, cais cov clutch disc los ntawm lub flywheel thiab cuam tshuam lub zog khiav.
Qhov no clutch disc yog sib xws nrog ntau yam ntawm ISUZU tsheb thiab cav:
Cov qauv tsheb:
ISUZU N -Series:
NHR, NKR, NPR, NQR (Lub Teeb & Lub Luag Haujlwm Nruab Nrab)
ISUZU Pickups & SUVs:
TFS, UBS, UCS (D-MAX, Trooper, Rodeo)
Compatible Engines:
4JB1 / 4JB1-T
4jj 2
4 BD1/4BD1-T
4HG1 / 4HG1-T
4 HK1-TC
4 BE1/4 HE1
OEM Hla- Cov lej siv
Rau koj qhov yooj yim, qhov no sib haum rau cov hauv qab no OEM thiab cov lej sib pauv:
Txheem hom:
8971354920, 8980806610, 8980116820, 8973778990, 8972571240, 8972179850, 8972072450, 8970805640, 8943752480, 8970663450, 8971041090, 5876100831
Hom ntawv Hyphenated:
8-97135492-0, 8-98080661-0, 8-98011682-0, 8-97377899-0, 8-97257124-0, 8-97217985-0, 8-97207245-0, 8-97080564-0, 8-94375248-0, 8-97066345-0, 8-97104109-0, 5-87610083-1
vim li cas thiaj xaiv peb
29 Xyoo Ntawm Kev Paub:
Txij li thaum xyoo 1997, peb tau ua tus thawj coj ntseeg hauv ISUZU qhov kev lag luam.
Ib -Stop Supply:
Peb nqa tag nrho ntau yam ntawm ISUZU qhov chaw-los ntawm lub cav cov khoom mus rau lub cev vaj huam sib luag- rau txhua tus qauv.
Ntiaj teb no Export Expertise:
Peb nkag siab cov qauv kev xa khoom thoob ntiaj teb thiab muab cov ntim khoom ruaj khov kom ntseeg tau tias koj cov khoom tuaj txog hauv qhov zoo.
Quality Assurance:
Txhua batch raug soj ntsuam nruj me ntsis kom ua tau raws li lossis dhau OEM cov qauv.
Plaub qhov kev xaiv zoo:
Nyiv Qhov Tseeb / BVP / Siab -Kev Ua Haujlwm Tom Qab / Tuam Tshoj ISUZU (Qingling) zoo rau Xaiv.
Order & Nug:
Nrhiav ib qho kev tsocai ntau lossis lwm yam ISUZU?Peb muab kev sib tw lag luam wholesale tus nqi rau cov neeg xa khoom thiab cov tswv nkoj thoob ntiaj teb.
Dab tsi yog Qhov txawv ntawm Plaub qhov kev xaiv zoo
Yam khoom
Cov ntaub ntawv ntim & Logistics
Peb muab cov khoom ntim khoom txheem kom ntseeg tau ntev -kev nyab xeeb hauv hiav txwv thiab huab cua:
Inner Packing:
Anti-xeb daim ntawv / hnab yas + Lub thawv xim tsis muaj xim lossis xim xim.
Ntim Ntim:
Muaj zog corrugated master carton (10-20 units ib thawv).
Palletizing:
Muaj rau kev txiav txim ntau los tiv thaiv kev puas tsuaj thaum caij tsheb npav.
Lub Sijhawm Lead:
1-3 hnub rau cov khoom lag luam; 15-30 hnub rau kev tsim khoom loj.
Yog xav paub ntxiv txog peb lossis xav kom peb pab koj nrhiav Isuzu spare qhov chaw, thov inbox rau peb.
Hu rau peb pab neeg nrog koj tus lej OEM, VIN, lossis cov ntsiab lus ntawm lub nkoj kom tau txais kev pom zoo meej.
